| Display（screen） | 7 inch TFT color display(16:9) |
| Video inputs | 2-CH inputs |
| Images | 800 R.G.B×480 dots |
| Format | NTSC/PAL |
| Power Supply | 12/32V DC |
| Power consumption | ＜7W |
| Operating temperature | -10 to +65° |
| MIRROR/NORMAL switch | Yes |
| Reversing gear is engaged | Automatically |
| Pick up Device | 1/3 1099 or 1/3 full HD CCD |
| TV System | PAL/NTSC |
| Picture Elements | 500H×420v |
| Horizontal Resolution | 560TVL or 700TVL |
| Sensitivity | 0 Lux(LED On) |
| Scanning System | 625 TVL/2 1 lnterlace |
| Synchronization | Internal |
| Infrared Spectum | N/A |
| S/N Ratio | 50 dB |
